Product Parameters
| Parameter | Value |
|---|---|
| Model | AE-LED22-HS |
| LCD Size | 22 inches |
| Resolution | 1920 x 1080 |
| Display Area | 478.66 x 260.28 mm |
| Aspect Ratio | 16:9 |
| Brightness | 250 cd/m² |
| Contrast Ratio | 3000:1 |
| Viewing Angle | 178°/178° |
| Response Time | 5 ms (Gray to Gray) |
| Color Depth | 16.7 million |
| Control Method | Panel |
| Power Input | 12V/3A |
| Input Interface | HDMI, VGA |
| Power Consumption | 22.5 W (≤0.5 W standby) |
| Adjustment Angle | Backward 15° ±2°, Forward 5° ±2° |
| Color | Black |
| Material | Flame retardant plastics |
| Dimensions | 494 x 282 x 42 mm |
| Package Size | 570 x 112 x 378 mm |
| Installation | Base, wall mount (75mm x 75mm) |
| Net Weight / Gross Weight | 2.2 kg / 3 kg |
| Package Size | 585 x 585 x 393 mm (5 pcs/carton) |
| Outer Packaging Weight | 16 kg |
| Working Temperature | -10°C to 40°C (±5°C) |
| Wet Working Environment | 10% - 90% RH |
| Attachment List | Stand, DC Power Supply, Warranty Card, Manual, HDMI Cable (gift) |
| Mode of Transport | According to customer requirements |
Features
HD Resolution: Provides 1920x1080 resolution. Supports 3840x2160/30Hz signals, compatible with many systems.
Grade A Screen: Adopts high-quality screens from top manufacturers. Ensures excellent display performance and reliability.
Fast response time: 5ms response time, suitable for fast-paced activities such as gaming and video editing.
New Backlight Architecture: Adopts advanced backlight design. Enhances visual effects and extends product life.
Self-developed Motherboard: Designed for surveillance applications. Improved image signal decoding and includes security features.
Intelligent Image Processing: Equipped with 10-bit processing chip. Enhances color accuracy and dynamic range for better visual effects.
Excellent Dark Processing: Combined with 3D noise reduction, suitable for low-light environments. Achieves natural transitions between light and dark areas.
Stable Image Quality: Uses progressive scanning to minimize flickering. Provides smoother and more stable image performance.
High Detail Fidelity: 10-bit chip ensures lossless detail processing. Avoids distortion in high-contrast scenes.
Lab Color Calibration: Adjusts color and gamma to specific needs. Optimizes performance for surveillance applications.
Stable Operation: Manufactured with industrial-grade materials. Guarantees reliable performance 24/7 with precise power supply.
Built-in Speakers: Includes dual speakers for audio playback. No external speakers required in most settings.
Convenient Playback: USB interface allows direct playback of media. Suitable for advertising and various commercial displays.
Multiple Interfaces: Provides HDMI, VGA, USB, CVBS and audio inputs. Meet different connection needs of various devices.
Business-specific features: After-sales service includes call center and online technical support, return and replacement, repair options.
User-friendly design: Flat screen and 178-degree horizontal viewing angle, suitable for presentations and meetings.
Advantages
High-quality display: Offers a large screen with Full HD resolution, 300 cd/m² brightness, and 1000:1 contrast ratio for crisp images.
Fast response time: Offers a 5ms response time for fast-paced activities like gaming and video editing.
Multi-interface compatibility: Equipped with HDMI and VGA ports, it can be easily connected to PCs and gaming consoles.
Business-specific features: Includes a 1-year warranty and customer support via call center and online technical assistance.
User-friendly design: Features a flat screen with multi-angle horizontal viewing angles, perfect for presentations and meetings.
Applications
Commercial Displays: Ideal for advertising and promotional displays in retail environments.
Surveillance Systems: Ideal for security and surveillance settings where high definition is required.
Educational Environments: Ideal for presentations and instructional videos in classrooms.
Corporate Environments: Ideal for conference rooms to display presentations and video calls.
Public Information Displays: Can be used in waiting areas or lobbies to provide information and entertainment.
Precautions
Be careful when transporting and handling;
Do not use in corrosive, flammable, or explosive places;
To avoid electric shock, cut off the power supply during installation, commissioning, and moving;
Do not install near heat sources to prevent product overheating and damage.
Ensure that all connectors are connected correctly and reliably;
Do not open the product cover without permission.
1.Does the monitor have built-in speakers?
Yes, the monitor comes with integrated speakers, which makes it convenient to play audio without external devices.
2.Can I mount the monitor on a wall?
Yes, the monitor is VESA compatible and can be easily mounted on a wall to save desk space.
3.What types of inputs does the monitor support?
The monitor supports HDMI and VGA inputs, which are compatible with a wide range of devices.
4.Does the monitor come with a warranty?
Yes, the monitor comes with a one-year warranty for peace of mind and support for any issues.
5.Can I use the monitor for professional graphic design?
Yes, the monitor's 10-bit color processing and high resolution make it suitable for graphic design work.
