Product Description
1、high-definition: 3840*2160 than the ordinary monitor clarity
2、power on the bottom left of the screen automatically detects the resolution of the input signal, clarity with data to speak
3、clear: delicate and realistic, transmitting the true color, showing the true nature of me
4、using industrial screen, high brightness, high contrast
5、the use of high-precision standard voltage regulator, designed for industrial equipment, support 24 hours × 365 days of uninterrupted work
6、using 10bit image chip processing technology, high pixel progressive scan, fine and realistic picture quality
7、Support intelligent 3D noise reduction, eliminate residual image function, dynamic brightness, contrast color optimization technology
8、the application of the world's leading LCD driver program, accurate restoration of the front-end signal, a strong sense of reality
9、LCD has a small size, low energy consumption, zero radiation, image stability, no impact on the eyes, natural health
10、6.5 ms extremely fast response, to avoid the image in the high-speed operation of the trailing phenomenon
11、the use of nanotechnology, the picture is more three-dimensional, transparent
Product Model : AE-LED55
Specification : AE-LED55-LY
Screen size : 55 inch
Display resolution : 3840*2160
Display ratio : 16:9
Brightness : 500cd/㎡(center point, typical value)
Contrast ratio : 3000:1
Viewing angle : 89/89/89/89 (Typ.)
Response time : 6.5ms (Gray To Gray)
Color depth : 1.07B (8-bit + Hi-FRC)
Control mode : Panel / remote control
Power input : 110V/220V 50Hz/60Hz
Input interface : HDMI/VGA/USB/DVI/BNC/RS232
Output port : RS232
Overall power consumption : 200W
Color : Black body
Material : professional fireproof iron case plastic frame (base is plastic)
Overall dimensions : 1249*730*72mm excluding the height of the foot (foot height 70mm)
Package size : 1379*861*220mm
Installation : base, wall hanging (200mm * 200mm)
Net weight / gross weight : 12.2kg/20.2kg
Working environment temperature : 20 degrees
Working environment humidity : 10%-90%RH
