AEVISION
Product Description
Ø HD: 2560*1080 high-definition resolution, 21:9 ultra-wide field of view , cinema-level wide visual feast, 30% larger than the traditional display area.
Ø Silky high refresh rate: Up to 120Hz refresh rate, the picture is smooth and smooth without tearing, and the game entertainment is one step faster.
Ø Stylish body: thin and light appearance, integrated metal frame, glass back panel, showing the texture.
Ø 178° viewing angle: Excellent wide viewing angle technology allows you to enjoy high-definition wonderful images and feel the beauty of true colors no matter at any angle .
Ø Using 8bit image chip processing technology, high-pixel progressive scanning, fine and realistic picture quality .
Ø Support intelligent 3D noise reduction, image afterimage elimination, dynamic brightness, contrast color optimization technology .
Ø Apply the world's leading liquid crystal drive scheme to accurately restore the front-end signal, with a strong sense of reality .
Ø Liquid crystal has small size, low energy consumption, zero radiation, stable image, no impact on eyes, natural and healthy .
Ø The 1 ms response speed avoids the smearing phenomenon of images during high-speed operation .
Ø Using nanotechnology, the picture is more three-dimensional and transparent .
Ø No flickering + low blue light shields harmful blue light bands, reduces interference from reflected light sources, and reduces eye damage
Ø Efficient and time-saving: The split-screen function or split-screen software that comes with Win10 and above can realize the viewing of the left and right windows on the same screen, saving switching time and further improving productivity.
Ø The design of the high-strength glass back panel is more scratch-resistant and can effectively reduce the problem of light leakage on the display.
panel properties | |
LCD size | 29 inches |
O/C | IPS |
light source | LED backlight |
resolution | 2560×1080 |
screen ratio | 21:9 |
HDR high dynamic image | support |
RBG glare | not support |
RTS/FPS display mode | support |
AMD FreeSync | support |
DC dimming | support |
slope | --- |
Machine Tilt | --- |
brightness | 250cd/ m2 |
dynamic comparison | 1000 : 1 |
refresh rate | 60/ 100 / 110/ 120Hz |
Reaction time | 1ms _ |
display color | 16.7M |
color gamut | 80% NTSC |
curvature | flat |
Camera | none |
Whether touch screen | no |
Whether with audio | no |
life | 60,000 H(typ) |
angle of view | H 178°/V 178° |
scene mode | 6 types |
Automatic shut-down | support |
color temperature mode | 4 types |
power properties | |
Voltage/Adapter | 12V/4A |
Overall power consumption | 30W |
Functional properties | |
Operation method | button |
Certificate | |
3C certification number | 2023010903520396 |
Energy efficiency class/number | Level 1/CQC23701377281 |
Working/storage environment | |
Working temperature/humidity | 0~50℃/20%~80% (no condensation) |
storage temperature/humidity | -10~60℃/5%~95% ( no condensation ) |
interface | |
input interface | HDMI+DP+USB+AUDIO OUT |
language | |
OSD | Simplified Chinese, English , French , etc. 14 kinds |
structure | |
Exterior color | black |
product architecture | Glass back panel + integrated metal middle frame |
wall size | 75*75 (mm) |
Total Weight | Net weight 3.9(kg)/gross weight 6.5KG |
Overall size | 687.2×423×158(mm) |
installation method | Pedestal/Wall Mounted |
